Description
SPECIFICATIONS OVERVIEW
(COMPLETE HDP5000E SPECS AVAILABLE AT HIDGLOBAL.COM)
Print Method: HDP Dye-Sublimation / Resin Thermal Transfer
Resolution: 300 dpi (11.8 dots/mm)
Colors: Up to 16.7 million / 256 shades per pixel
Print Speed (Batch Mode): **
• Up to 27 seconds per card/ 133 cards per hour (YMCK* with transfer)
• Up to 33 seconds per card/ 109 cards per hour (YMCKK* with transfer)
Accepted Standard Card Sizes: CR-80 (3.370˝ L x 2.125˝ W / 85.6 mm L x 54 mm W)
Accepted Card Thickness: .030˝ (30 mil) to .050˝ (50 mil) / .762 mm to 1.27 mm
Input Card Cartridge Capacity: 100 cards (.030” / .762mm) – Optional dual input hopper or 200-card input hopper available for a total
input capacity of 200 cards
Output Hopper Card Capacity: 200 cards (.030˝ / .762 mm)
Software Drivers: Windows® 10 / 11 / Server 2016 / Server 2019 / Server 2022
Print Area: Over-the-edge on CR-80 cards
Warranty:
Printer – Four years including one year of free printer loaner support with option to purchase a second
year of printer loaner support (U.S. only)
Printhead – Lifetime, unlimited card passes
Options:
• Dual-sided printing
• Lamination module
• Magnetic stripe encoder
• Contact smart card encoder
• Contactless smart card encoding modules
• Single-wire Ethernet or USB 2.0 interface for inline
printing and encoding (Note: single-wire Ethernet
encoding is available with a third-party license)
• 200-card input hopper
• Dual input card hopper
• Secure Proprietary Consumables
• Printer Cleaning Kit
Included Software FARGO Workbench™ diagnostic utility with Color Assist spot-color matching included with driver
* Indicates the ribbon type and the number of ribbon panels printed where Y=Yellow, M=Magenta, C=Cyan, K=Resin Black
** Print speed indicates an approximate print speed and is measured from the time a card drops into the output hopper to the time the next card drops into the output hopper.
Print speeds do not include encoding time or the time needed for the PC to process the image. Process time is dependent on the size of the file, the CPU, the amount of RAM
and the available resources at the time of the print.
A HISTORY OF PROVEN EXPERTISE YOU CAN TRUST FARGO
Introduced High Definition Printing (HDP®) in 1999, and we’ve been advancing the technology ever since. Built on seven generations of proven retransfer technology over the last 25 years, the FARGO HDP5000e ID card printer emerges as the next iteration of FARGO high definition printing solutions, redefining the standards of reliability, usability, security and printing excellence. Offering superior-quality printing for every need — from sharp and vibrant photo ID cards to multifunctional, high-security applications — and virtually every budget, the FARGO HDP5000e delivers outstanding value. Many buyers also search for the FARGO HDP5000e ID card printer price in Pakistan, the FARGO HDP5000e ID card printer price, or simply the FARGO HDP5000 price, showing its high demand in the market.
INNOVATION INSPIRES BY CUSTOMERS
Based on valuable feedback from our customers, partners and team, FARGO has developed a new printer that delivers more new features, improved convenience and superior performance while maintaining the excellent quality of the HDP5000 series.
UNPARALLELED RELIABILITY
The HDP5000e is exceptionally reliable, which means less overall maintenance and decreased printer downtime. From its reinforced connection points and streamlined module attachment to its advanced card type selector, the HDP5000e was designed for dependability inside and out. The printer’s connectivity reinforcements strengthen and protect the USB, Ethernet and power cable connection points — increasing overall resilience and reducing the risk of main board damage or intermittent connectivity — and ensuring stable and reliable operation and data transfers. The printer’s streamlined module attachment ensures a smooth, unobstructed card path and helps eliminate common issues such as internal card jams and misalignment — while its advanced card selector and automatic settings adjustments help safeguard against delamination, card jams, and subsequent consumables and card waste. For reliable, uninterrupted ID badge and card printing, reduced maintenance and consistent, stunning print quality — you can rely on the FARGO HDP5000e. Many organizations also look for the Fargo HDP5000 price, compare the Fargo ID Card Printer price, or check the latest FARGO printer price in Pakistan before making a purchase.
USABILITY ENHANCEMENTS AT EVERY TURN
Whether your card printer operators are seasoned IT professionals or new users, a solution that is easy to set up, use and maintain over the long term will help your card program run successfully for years to come. With its robust features, the HDP5000e adds convenience and ease of use and streamlines everyday operations. Its user-friendly, high-definition SmartScreen™ interface provides easy-to-understand notifications and helpful, walk-through prompts for setup, maintenance and troubleshooting — making it easily accessible to virtually all skill levels. Thoughtfully designed, the HDP5000e provides easy access to the card path without any tools, as well as easy access to the film and ribbon drawer assemblies. It also boasts a sleek and smooth, easy-to-clean exterior — sporting a professional, high-quality appearance while simplifying maintenance routines.
SECURITY FROM END TO END
Built-in security features help ensure the FARGO HDP5000e plays an integral role in the overall security of your card issuance program. Here’s how: • Resin scramble data protection — This unique feature adds an additional layer of security by scrambling and subsequently concealing any information printed with a resin panel. Used ribbon panels are rendered indecipherable, safeguarding cardholder data from fraudulent use. • AES 256 data encryption — Encrypted print job data packets further protect sensitive cardholder data while in transit, guaranteeing data integrity and authentication to the final issuance endpoint The HDP5000e is also equipped with an Ethernet port and internal print server making it ideal for networked operations. Due to its inherent portability and exceptional reliability, the printer is also a perfect fit for distributed issuance environments. Simply put, the HDP5000e is the solution of choice for countless scenarios.
HIGH DEFINITION PRINTING HIGH DEFINITION PRINTING
delivers the highest image quality layered on the highest functioning cards. Because HDP film is fused directly to the surfaces of proximity or smart cards, it naturally conforms to ridges and indentations created by embedded electronics inside the card — ensuring flawless, sharp looking, finished credentials every time.
POWERFUL PERFORMANCE FOR LARGE WORKLOADS
Designed to meet the high-volume needs of mid-to-large corporations, universities, healthcare facilities and government agencies, the HDP5000e features increased card-by-card performance over previous HDP5000-series models. At up to 133 cards per hour, the HDP5000e is among the fastest printers in its class. The HDP5000e’s advanced electronic platform makes the printing process faster and more accurate, resulting in higher resolution and clearer images. Its enhanced memory and processing capabilities complete print jobs more efficiently, especially where high-volume printing is required.
A CLOUD-READY SOLUTION
Fully compatible with HID’s cloud-based card issuance platform, HID FARGO Connect™, the HDP5000e empowers today’s organizations to leverage the cloud to create superior-quality, multifunctional employee badges and other secure identity credentials — and issue them from anywhere.
ENHANCED COLOR PROFILE FOR SUPERIOR IMAGERY
Colors are vibrant. Images and text are crisp. An enhanced color profile ensures that ID cards printed on the FARGO HDP5000e card printer do more than protect your organization — they reflect the value you place on your brand. Its highly vivid imagery also aids in visual ID verification.
MULTIPASS FUNCTIONALITY FOR INCREASED DURABILITY
For increased durability, additional HDP film layers may be optionally applied with the printer’s inclusive multipass* function — providing the enhanced protection that high-use IDs and cards demand.
FLAWLESS CREDENTIALS
The FARGO HDP5000e is also right for organizations that demand more functionality from their ID cards. Encoding options can be configured to produce highly secure contact and contactless smart cards that address your specific needs. The HDP5000e can also print up to the very edge of smart chip contacts and virtually over the edge of each card, resulting in professional and polished credentials.
A MODULAR SYSTEM THAT CAN GROW WITH YOUR NEEDS
The HDP 5000e offers the versatility to meet your card application needs today and in the future. With add-on dual-sided printing, encoding and lamination modules, the system’s flexible architecture lets you expand or reduce production instantly. For greater system capacity, an optional dual input card hopper lets you easily manage multiple card types and higher card volumes, expediting even the biggest production jobs. An optional 200-card input hopper is also available. For one-step, inline printing and encoding, multiple, field-upgradable encoder options are also available.
PERSONALIZE CARDS IN ONE SEAMLESS STEP FARGO
HDP5000e card encoding modules enable organizations to print and encode credentials in a one-step, inline process — saving both time and money. In a single step, the printer/encoder personalizes smart cards with text and color and reads/writes data from/to the card’s smart chip. This inline processing speeds ID issuance and effectively eliminates the potential for manual data entry errors that occur in the common two-step card personalization and data encoding process. Offering a wide array of inline card encoding technologies, the HID FARGO HDP5000e ID card printer can meet the needs of virtually any secure credential issuance program. Whether an organization requires a low cost ID card printer for small setups or a professional color ID card printer for high-quality results, this model delivers. Furthermore, because modules are fully field-upgradeable, encoding can be added or changed at any time to support new card personalization or evolving security needs as your requirements change over time.
PRINT AND ENCODE MULTIFUNCTION CARDS FOR A VARIETY OF APPLICATIONS
GOVERNMENT ID
Government agencies demand reliable and secure card issuance for an array of credentials spanning drivers’ licenses, national IDs, employee and contractor badges and more, The HDP5000e is a versatile, easy-to-use and cost-effective printer/encoder for producing highly secure, durable, government-issued IDs — cards that are resistant to wear, tear and tampering. Optional Visual Security Elements (VSEs) provide added fraud and counterfeit deterrence.
CORPORATE ID
From medium-sized companies and large enterprises to healthcare campuses, the HDP5000e streamlines the issuance of multifunctional employee, contractor or visitor ID cards used for visual identification, access control, time and attendance, and payment functions.
STUDENT ID
Yesterday’s student photo ID is today’s multifunction campus One Card. A single card can be used for physical access to buildings, logical access to networks, library checkout and other services, as well as cashless and debit card transactions on and off campus. The HDP5000e makes on-the-spot issuance of these multifunctional student IDs fast and efficient.
LEVEL UP YOUR CARD PRINTING EXPERIENCE
Only one card printer offers 7th generation retransfer technology for every need — from sharp and vibrant photo ID cards to multifunctional, high security ID badge and card applications, the customer-inspired FARGO HDP5000e is the solution of choice for superior image quality, ease of use and printer reliability.
LEARN MORE TO DAY
To learn more about the FARGO HDP5000e or to find a FARGO dealer or integrator near you, visit hidglobal.com.
